System Overview
2.2. Take A Tour
2.2.1. FPC-7900
2.2.1.1 Front View
HDD/SSD Tray
DVI-D port
USB 3.0 ports
RTC battery
service window
CFast/SIM card window
Power button
VGA port
GbE LAN ports
Antenna holes
2.2.1.1 Front View
DC-IN
Ground
Ignition Switch
HDMI
DisplayPort
RS-232/422/485
Selectable Serial Ports
RS-232 Serial Ports
Mic in
Line Out
DIO/LPT Port
(Selectable)
