3.2. Jumpers and Connectors
3.2.1. Jumpers
➊ JME1
Function:
ME Flash Selection
Jumper Type:
2.54mm pitch, 1x2-pin header
Setting:
Pin Description
Short
ME Flash enable
1 2
Open
ME Flash disable (default)
1 2
➋ JME2
Function:
Clear CMOS Selection
Jumper Type:
2.54mm pitch, 1x2-pin header
Setting:
Pin Description
Short
Clear CMOS
1 2
Open
Keep CMOS (default)
1 2
➌ JACCON2
Function:
Vehicle Acc mode selection
Jumper Type:
Onboard 2.00mm-pitch 2-pin header
Setting:
Pin Description
Short
For automation mode (default)
1 2
Open
For vehicle mode
1 2
