Arbor Technology FPC-7900 - Fpc-790 X

- 10 -
System Overview
2.2.2. FPC-790X
2.2.2.1 Front View
HDD/SSD Tray
DVI-D port
USB 3.0 ports
RTC battery
service window
CFast/SIM card window
Power button
VGA port
GbE LAN ports
Antenna holes
2.2.2.2 Rear View
PCI/PCIe slots
DC-IN
Ground
Ignition Switch
HDMI
DisplayPort
RS-232/422/485
Selectable Serial Ports
RS-232 Serial Ports
Mic in
Line out
DIO/LPT Port
(Selectable)
