Arbor Technology FPC-7900 - CPU and Memory Installation

- 36 -
Installation & Maintenance
2. After removing the screws, carefully lift and remove the bottom cover from
the computer.
The bottom of the computer comes to view.
4.1.2. Install CPU
1. Remove the top cover from the computer as described in 4.1.1.2. Remove
Top Cover on page 32.
2. Locate the CPU socket on the main board
