Arbor Technology FPC-7900 - Jumpers and Connector Details

- 16 -
Engine of the Computer
Jumpers
Label Description
➊JME1
ME FLASH Selection
➋JME2
CMOS Settings
➌JACCON2
Ignition power mode
Connectors
Label Description
①SW1
Power button
②CF1
CFast Card Type I/II slot
③VGA1
Analog RGB & DVI-D connector
④⑤⑥LAN3, 2, 1
GbE RJ-45 Ethernet connector & dual USB3.0 connectors
⑦DPG1
External 80 port
⑧JPIC1
PIC programming pin header
⑨CPUFAN1
Fan power connector
⑩AUDIO1
Audio connector
⑪COM3
RS-232 Serial Port (Panel label: COM6, COM5)
⑫COM2
RS-232 Serial Port (Panel label: COM4, COM3)
⑬COM1
RS-232/422/485 Selectable Serial Port (Panel label: COM2, COM1)
⑭HDMI_DP1
HDMI/DP combo connector
⑮HDMI1
HDMI connector
⑯PWRIN1
DC adapter power input
⑰POEOUT1
PoE power connector
⑱JACCON1
Vehicle Acc mode selection
⑲DIO1
Digital IO Connector
⑳LPT1
On-board parallel port connector
21 22
MC1, 2
PCI Express Mini-card full/half size socket
23
SYSFAN1
Fan power connector
24
SIM1
SIM card socket
25
SCPIN1
Supercapacitor power in
