- 71 -
BIOS
Mode Select
Select RS-232 (default), RS-422, RS-485, RS-422
Termination Resistor or RS-485 Termination Resistor
Parallel Port Conguration
Parallel Port
Enable (default) or Disable Parallel Port (LPT/LPTE).
Change Settings
Select an optimal setting for Super IO device.
► Options:
Auto (default) ;
IO=378h; IRQ=5;
IO=378h; IRQ=5, 6, 7, 9, 10, 11, 12;
IO=278h; IRQ=5, 6, 7, 9, 10, 11, 12;
IO=3BCh; IRQ=5, 6, 7, 9, 10, 11, 12;
Device Mode
Change the printer port mode:
► Options:
STD Printer Mode (default) ;
SPP Mode;
EPP-1.9 and SPP Mode;
EPP-1.7 and SPP Mode;
ECP Mode;
ECP and EPP 1.9 Mode;
ECP and EPP 1.7 Mode
Super IO Chip F81216SEC Settings
Serial Port Conguration
Serial Port
Enable (default) or Disable Serial Port (COM).
Change Settings
Select an optimal setting for Super IO device.
► Options for Serial Port 1:
IO=240h; IRQ=5 (default) ;
IO=240h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=248h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=250h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=258h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
► Options for Serial Port 2:
IO=248h; IRQ=5 (default) ;
IO=240h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=248h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=250h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
IO=258h; IRQ=3, 4, 5, 6, 7, 10, 11, 12;
