Table 1-6 (Ceiling-Mounted)
Part Name Figure Q’ty Remarks
Special washer
4
Drain insulator
1
Flare insulator
2 sets
Insulating tape
2
Vinyl clamp
8
Eyelet
1
Full-scale installation
diagram
1
Drain hose
1
For temporarily suspending indoor unit from ceiling
For drain hose joint
For gas and liquid tube joints
For gas and liquid flare joints
For flare and drain insulator
For pow
er supply inlet
T10
T5
T3
White
(heat-resisting)
For drain hose connection
2
Hose band
L140
For main unit + PVC pipe joints
Printed on container box
Table 1-7 (Concealed-Duct)
Part Name Figure Q’ty Remarks
8
Flare insulator
2
Insulating tape
2
Drain insulator
1
Hose band
1
Packing
1
Drain hose
1
Sealing putty
1
Vinyl clamp
8
Booster cable*
1
For suspending indoor unit from ceiling
For gas and liquid tubes
For gas and liquid tube flare nuts
For drain hose joint
For securing drain hose
For drain joint
For sealing recessed por tion of power supply
F
or flare and drain insulators
* Booster cable is housed inside the electrical component box.
Washer
Connector for changeover to HT tap.
 Use 3/8" for suspending bolts.
 Field supply for suspending bolts and nuts.
