10
2.2 Unpacking
Note!
Before installing make sure the usher-disinfector has not
been damaged in transit.
The following items must accompany the usher-disinfector when it
is delivered:
• Two cabinet keys
• One folder containing documentation
The usher-disinfector is supplied securely bolted to a pallet.
1. Remove the packaging.
2. Move the usher- disinfector as close to the installation
position as possible, when still secure to the pallet using
mechanical means.
3. Remove the bolts securing the usher disinfector to the
pallet.
001400
Figure 1. Removal of anchoring bolts
4. Assess the usher-disinfector for lifting from the pallet. Use
at least two persons to lift the usher-disinfector to the oor or
to a low level wheeled trolley to aid movements to the nal
position.
