5 TECHNICAL DATA
5.1 Connections
Connection Connection
requirements
Flow requirements
Cold water (CW) 15 mm (G½") 100 – 800 kPa
(1 – 8bar)
20 l/min
Hot water (HW) 15 mm (G½") 100 – 800 kPa
(1 – 8bar)
20 l/min
Drain (D) Ø 90 mm or Ø 110 mm N/A Top 1 l/sec
5.2 Environmental requirements
Room temperature 5 – 40°C (41 – 104°F)
Air humidity < 80 % at 31°C (87°F)
Max. surface temperature 40°C (104°F)
5.3 Water consumption
Economy program 11 liters ± 10%*
Normal program 18 liters ± 10%
Intensive program 25 liters ± 10%
5.4 Exterior dimensions
FD1800, FD1810 FD1805
Model Freestanding Under-bench
Width 450 mm (17" 11/16) 900 mm (35" 7/16)
Depth 580 mm (22" 3/4) 620 mm (24" 1/2)
Height 1320 mm (51" 7/8) Without worktop:
• 870 mm (34" 3/16)
With worktop (option):
• 900 mm (35" 7/16)
5.5 Weight
FD1800, FD1810 FD1805
Model Freestanding Under-bench
Weight 100 kg (220 lb) 120 kg (265 lb)
