SP-16: In the parallel installation Systems, LOP calls are connected to this board.
BC-BUT: It is the landing call button without indicator.
BCD-2X: landing call button with two parts and a dotmatrix indicator.
BCD-3X: landing call button with three parts and a dotmatrix indicator.
BCD-LCDA: 128x64 resolution LCD. The idicator can be used both inside the car and landing or door indicator.
CAR PANEL CONTROLLER BOARDS
In Arcode, 2 different boards can be used optionally for car calls. If car call buttons will be connected with socket type,
CPC board should be used. If car call buttons will be connected wire by wire with terminal, CPC-T board should be used.
In the systems of more than 16 stops, using CPC-T board is not possible.
1-DIP SWITCH SETTINGS OF CPC BOARD
ARCODE, that can work with two-door support up to a total of 64 stops, collects car calls with the help of a CPC card.
Each CPC card can serve up to 24 stops. If there are more than 24 floors or on condition that it has two doors, two CPC
cards must be used. For an elevator with 64 stops and two doors, a sum of 6 CPC cards must be used. The dipswitch
which is located on CPC board is used to determine working type and door settings.
Dipswitch-1
Dipswitch-1
Dipswitch-3
Dipswitch-4
0
0
1
0
CPC-1A
Up to 24 floors
0
1
1
0
CPC-2A
Up to 48 floors
1
0
1
0
CPC-3A
Up to 64 floors
0
0
0
1
CPC-1B
Up to 24 floors
for 2nd door
0
1
0
1
CPC-2B
Up to 48 floors
for 2nd door
1
0
0
1
CPC-3B
Up to 64 floors
for 2nd door
0
0
1
1
CPC-1AB
Up to 24 floors
0
1
1
1
CPC-2AB
Up to 48 floors
1
0
1
1
CPC-3AB
Up to 64 floors
For example: If you have a one-door system up to 24 floors, dip switch settings must be done “0010”. “ON” on the dip
switch means 1.
Appendix-1
Figure-2: dipswitch settings of CPC board
