SP-16 SETTINGS
SP-16 card is used when buttons are not serial communication (CANBus). It can serve up to 16 floors at most. In one way
collective external calls can be collected up to 16 floors with a SP-16. In case of two way collective, calls can be collected
up to 9 floors with a SP-16. For double buttons 16 floors two SP-16 must be used. Dip switch settings must be done
according to the following table.
CALL TYPE / DOOR /
DIRECTION CHOICE
DS1
DS2
DS3
I1 I2 I3….…..I7 I8 I9 I10….........I14 I15 I16
One-Way Collective (2-16 Stop)/
Door A /
Down
0
0
0
301 202 203…………………………...214 215 216
One-Way Collective (2-16 Stop)/
Door B /
Down
0
0
1
301 202 203…………………………...214 215 216
Two-Way Collective (2-9 Stop) /
Door A /
Up & Down
0
1
0
301 302 303…..307 308 202 203…….207 208 209
Two-Way Collective (2-9 Stop) /
Door B /
Up & Down
0
1
1
301 302 303…..307 308 202 203…….207 208 209
Two-Way Collective (10-16Stop)
Door A /
Up
1
0
0
301 302 303……………………………314 315 -
Two-Way Collective (10-16Stop)
Door B /
Up
1
0
1
301 302 303……………………………314 315 -
Two-Way Collective (10-16Stop)
Door A /
Down
1
1
0
- 202 203……………………………214 215 216
Two-Way Collective (10-16Stop)
Door B /
Down
1
1
1
- 202 203……………………………214 215 216
Appendix-1
Figure-3: SP-16 dipswitch settings
