Switch number 4 is used for indicator outputs. If switch number 4 is 1, it gives inverted gray output. If it is 0, it gives
output as gray. The switch number 5 is free for future features. The dip switch number 6 must be “0”. If it is “1”, it will
work in test mode. “ON” on the bottom switch means “1”.
MEANING OF 7-SEGMENT MESSAGES ON ARCODE
INIT:
Elevator goes bottom floor for reset(Initialising)
UpEn:
Enca board is being updated (Updating Enca)
O-in:
Only inspection
notu:
Needed autotuning(No Tuning)
noSh:
Needed Shaft learning (No Shaft Learning)
120-:
No 120 signal
Fire:
Fire mode
RcLL:
Recall mode
inSP:
Inspection mode
tune:
Autotune is being done
SHFL:
Shaft learning is being done
ErXX:
There is an error that XX code. (If it is flashing this means elevator is blocked)
rtrX:
Elevator go out an error and it will retry X seconds later (x:1-5)
L. X:
Elevator is waiting at X. floor door zone
L X:
Elevator is waiting at X.floor but the car isn’t at door zone.
1.58:
Elevator is going with speed of 1.58 m/s
-0.35:
Elevator is going downward with speed of 0.35m/s
door:
There is a call but the door is open
EUAC:
Rescue mode
Appendix-2
