2-DIP SWITCH SETTINGS OF CPC-T BOARD
CPC-T board can work up to 16 stops.
Dipswitch-1
Dipswitch-2
Dipswitch-3
Dipswitch-4
ON
Door-A enable
Door-B enable
Gray outputs
Outputs are inverted
OFF
Door-A disable
Door-B disable
Binary outputs
Outputs are normal
CPC-T board can be optionally used instead of CPC board. As seen in the table above, the dip-switch settings are
different from each other. So, please pay attention this case while doing dip-switch settings.
For CPC-T board, car call button connections are done wire by wire with terminal. If the system has more than 16
stops, it is not possible to use CPC-T board.
IO-0210 BOARD
In some cases, programmable inputs and outputs may not be enough. Then, this IO-0210 board would be useful. This
board gives 2 inputs and 10 transistor outputs to the user.
There are 8 dip-switches. The logic of these dip-switches is as follows:
For outputs, 1 and 2 dipswitches are used to select the group number of output:
1
2
Prog.output
OFF
OFF
1st group
OFF
ON
2nd group
ON
OFF
3rd group
ON
ON
4th group
From “Programmable outputs” parameter, the outputs should be assigned from related group number. (Tools  device
parameters  programmable outputs  IO-0210 board outputs)
1 pc. IO-0210 board gives 10 programmable transistor outputs to the user.
For inputs, other 6 dipswitches (from 3(MSB) to 8(LSB)) works with a binary logic. For example;
MSB: Most Significant Bit (3rd dip-switch)
LSB: Least Significant Bit (8th dip-switch)
You can program 64 different IO-0210 boards for inputs.
000000 “IO-0210-1 board PI1 and IO-0210-1 board PI2”
000001 “IO-0210-2 board PI1 and IO-0210-2 board PI2”
000010 “IO-0210-3 board PI1 and IO-0210-3 board PI2”
000011 “IO-0210-4 board PI1 and IO-0210-4 board PI2”
000100 “IO-0210-5 board PI1 and IO-0210-5 board PI2” and so on...
This can be chosen from 0 up to 63. (64 pcs.)
