ASCOM d41 User Manual

TD 92582GB
2009-12-15/ Ver. C
User Manual
Ascom d41 DECT Handset
23
6.3 During a Call
Note: Some of these functions are system dependent. The parameters are set up in the
Portable Device Manager (PDM), see Configuration Manual, Ascom d41 DECT Handset,
TD 92641GB, and Installation and Operational Manual, Portable Device Manager (PDM),
Windows version, TD 92325GB.
If configured in the PDM/IMS2, it is possible to call an emergency call while the handset/
keypad is locked. During the ongoing emergency call, the soft key "More" and the soft
key "R" are disabled.
6.3.1 Adjust the Volume during a Call
On the navigation key, press and to increase and decrease the volume, respectively.
The handset will now store and keep the new volume level.
6.3.2 Open Contacts during the Call
1 Press the "More" Soft key during the call.
2 Select "Contacts".
3 Press "Select".
4 Select "Call contact" for searching a local or company phonebook
1
contact, or
select "Central phonebook"
1
for searching a central phonebook contact.
5 Press "Select".
6 Select or search contact.
Note: It is possible to call the selected contact by pressing "Call". When calling the
contact, the first call will be put on hold. See also 6.3.4 Start a New Call during
Conversation.
6.3.3 Turn the Microphone on/off during a Call
1 Press the "More" Soft key during the call
2 Select "Microphone off"
3 Press "Select".
The icon indicates a silenced microphone. This means that the other part in an
ongoing call cannot hear you. To turn the microphone back on, do as follows:
1 Press the "More" Soft key during the call.
2 Select "Microphone on".
3 Press "Select".
It is also possible to turn the microphone off/on by a long press on .
6.3.4 Start a New Call during Conversation
1 Press the "More" Soft key during the call.
2 Select "New Call"
2
.
3 Press "Select".
4 Enter number, or press to access the phonebook.
1.Applicable for d41 Advanced only.
2.Visible if defined in the PDM.

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
