ASCOM d41 User Manual

TD 92582GB
2009-12-15/ Ver. C
User Manual
Ascom d41 DECT Handset
28
8 Contacts
The handset has a local phonebook with 250 entries, where names and numbers freely
can be added, deleted, and edited by the user. The phonebook lists all names in
alphabetical order, where three numbers can be added for each contact, that is, work
number, mobile number, and other number.
For more informarion on how to add, edit, or delete a contact, see 9.2 Contacts on page
31.
In addition, a company phonebook
1
with up to 500 entries can be downloaded to the
phone via the PDM, see 11.1 Software Upgrade and Additional Features on page 41. The
company phonebook name and numbers cannot be edited or deleted by the user. The
phonebook lists all names in alphabetical order.
The local and company phonebook appears in the same list but the company contacts are
indicated by a “Locked entry” icon in front of the name. The company contact includes
work number only. See 6.2.5 Dial a Number from the Company Phonebook on page 22
for more information. The local and company phonebook can also be accessed by pressing
the soft key in idle mode.
It is also possible to access a central phonebook
1,2
, see 6.2.4 Dial a Name from the Central
Phonebook on page 22. The user then sends a request to a messaging server with the first
characters entered, and the messaging server will return a list of names and numbers that
matches the search.
1.Applicable for d41 Advanced only.
2.This is system dependent

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
