User Manual
Ascom d41 DECT Handset
34
9.3.1 Sound and Alert Settings
Adjust the Ringer Volume
1 Select "Sound & Alerts".
2 Select “Volume”.
3 Adjust the volume by using and on the navigation key.
4 Press "Back" to save the setting.
Select Ring Signals
1 Select "Ring signals".
2 Select "Internal call", "External Call", or "Callback"
1
.
3 Press "Select".
4 Select ring signal. It is possible to listen to the selected ring signal by pressing the
"Play" soft key. The ring signal will be repeated until the "Stop" soft key is pressed.
5 Press "Select".
Turn the Vibrator on/off
1 Select “Vibrator alert”.
2 Select “On”, “On if silent” (i.e. the vibrator is on when the handset is muted), or
“Off”.
3 Press "Select".
4 Press "Back" to save the setting.
Set the Key Sound
This means that every time a key is used, a low sound is heard.
1 Select “Key sound”.
2 Select “Silent, “Click”, or “Tone”.
3 Press "Back".
It is possible to listen to the key sound by pressing the "Play" soft key.
9.3.2 Select Headset Profile
1 Select "Headset".
2 Select "Mic on boom", "Mic on cable", or "Customized headset profile"
2
3 Press "Select".
9.3.3 Display Settings
1 Select “Display”.
2 Select “Contrast”.
3 Adjust the contrast by using the and on the navigation key.
4Press "OK".
5 Press "Back".
1. "Callback" is only applicable if defined in the PDM/IMS2. See also 6.3.10 Call Back on page 25 for more information.
2."Customized headset profile" is only visible if the headset profile has been configured in the PDM/IMS2.

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
