ASCOM d41 User Manual

TD 92582GB
2009-12-15/ Ver. C
User Manual
Ascom d41 DECT Handset
47
14.2 Attach the Hinge-type Clip
Attach the hinge-type belt clip as described in the illustration below.
Figure 8. Attach the hinge-type clip into position.
14.3 Attach the Swivel-type Clip
Attach the swivel-type belt clip as described in the illustration below.
Figure 9. Attach the swivel-type clip into position.
14.4 Easy Replacement
Easy replacement can be used if a handset needs to be replaced due to, for example, a
broken display.
Note: If the electrical connection is damaged, it is not possible to follow the Easy
Replacement procedure. Depending on fault, it might work to do a replacement via PDM/
IMS2. See Configuration Manual, Ascom d41 DECT Handset, TD 92641GB.
Figure 1.

ASCOM d41 Specifications

General

Type	DECT telephone
Answering machine	No
Mounting type	-
Product color	Gray
Speakerphone	Yes
Phonebook capacity	500 entries
Languages support	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SLK, SWE, TUR
Standby time	180 h
Battery recharge time	4 h
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Number of handsets included	1

Weight and Dimensions

Depth	24 mm
Width	53 mm
Height	133 mm
