SECTION 4
MAINTENANCE
52
Remove the Service Station
1. Open the Front Cover (hinged at
bottom). Open the Top Cover.
Release the two latches and open the Print
Engine Clamshell. The Service Station will
not fully eject with the Clamshell closed.
2. Open the Printer Toolbox. Click “Eject
Service Station”. Once the Printer
pushes the Service Station out, turn the
Printer OFF.
TURN PRINTER POWER OFF.
WHENEVER POWERING DOWN UNIT, ALWAYS:
1. PRESS THE POWER BUTTON ON THE CONTROL PANEL.
2. WAIT FOR THE PRINTER TO STOP PROCESSING.
3. THEN PRESS THE MAIN POWER SWITCH ON THE REAR PANEL.
3. Carefully slide the Service Station out of the Service
Station port. NOTE: Do not pull Service Station all the
way out until you disconnect the Ribbon Cable.
NOTE: Place an absorbent towel under the Service
Station before you remove it to catch any drips or leaks.
