Asus RS720-E9-RS8 - Page 46

Chapter 2: Hardware Information
2-18
PCIe slot Operation mode
Slot 8 x16
Riser card bracket 3
Riser card bracket 3 supports PCIe Gen3 slots 6-7 top to bottom. Slot 7 can be auto-switch to
x16modewhenx16cardispopulatedwhereasslot6willbedisabled.
PCIe slot Operation mode
Slot 6 x8 N/A
Slot 7 x8 x16
Riser card bracket 4
Riser card bracket 4 supports PCIe Gen3 slot 8.
PCIe slot Operation mode
OCP Mezzanine x16
OCP Mezzanine slot
OCPMezzanineslotsupportsPCIeGen3x16.
