3.2 Markings
Markings provide instructions and information. They
also warn of hazards. For convenience and safety,
keep all markings in legible condition, replacing them
when damaged or missing. Replacement markings are
available from the factory.
A brief description of all markings provided on the
compressor is given hereafter. The precise location of
all markings can be found in the parts manual of this
compressor.
Danger, heat flat
Risk of fire.
This label is required for On
Road transport
Prohibition to open air valves
without connected hoses
Rotation direction
Air suction
Lifting point
3
The guiding rods may not be
used to lift the compressor.
Always use the indicated lifting
points for lifting.
Forklift slots
Release brake and raise locking
pad before towing.
Compressor oil drain
Engine oil drain
Engine coolant drain
Fuel drain
Warning!
Part under pressure
Do not stand on outlet valves
Switch enable pre-heater and
switch internal lights
Do not open doors while the
motor is running
Air discharged from this unit is
not suitable for human
consumption without the
installation of special equipment.
Inhalation may cause serious
injury or death.
Battery switch.
Battery conditioner
Atlas Copco engine oil
Atlas Copco coolant
