- 76 -
7.4 Compressor control module trouble shooting
7.4.1 Process information
While the compressor is running, the operator can take a brief look at all the incoming compressor and engine data, by pressing the Process Info button.
This can be very useful for trouble shooting over the phone.
7.4.2 Fault codes
There are several parameters that are continuously watched.
When one of these parameters exceeds its specified limit the compressor will react depending the present status of the control box.
Alarm code Alarm text Fail class Trigger
1231 FUEL FILL CHECK Warning PC
1503 INITIAL OVERHAUL REQUIRED Warning PC
1522 MINOR OVERHAUL WITHIN ** H Warning PC
1523 MINOR OVERHAUL WITHIN ** D Warning PC
1524 MINOR OVERHAUL REQUIRED Warning PC
1552 MAJOR OVERHAUL WITHIN ** H Warning PC
1553 MAJOR OVERHAUL WITHIN ** D Warning PC
1554 MAJOR OVERHAUL REQUIRED Warning PC
2000 EMERGENCY STOP INPUT Shutdown PC
2040 REMOTE EMERGENCY STOP Shutdown PC
2070 COOLANT LEVEL LOW WARNING Warning PC
2080 COOLANT LEVEL LOW SHUTDOWN Shutdown PC
2090 ∆P AIRFILTERS HIGH Warning PC
2100 NO PROJECTFILE DOWNLOADED Warning PC
3000 FUEL LEVEL LOW WARNING Warning PC
3010 FUEL LEVEL LOW SHUTDOWN Controlled Stop PC
3020 FUEL LEVEL SENSOR CIRCUIT Warning PC
3150 AIR DISCHARGE WARNING Warning PC
3160 AIR DISCHARGE SHUTDOWN Shutdown PC
3170 AIR DISCHARGE PRESSURE SENSOR CIRCUIT Warning PC
