- 37 -
Secondary Main view - Engine view
MAIN VIEW
LOADED
10.3 bar1300RPM1286h
2
3
4
1
5
40%
1 View, Overhaul, Auto load, Preset,
Active operation mode indication
2 Active compressor status
3 Navigation: toggle between main view
and engine view
4 Engine info
5 Alarm indication and compressor info
ENGINE WARNING LAMP - AMBER
LED steady on: low alarm
LED flashing slow: medium alarm
LED flashing fast: high alarm
ENGINE SHUTDOWN LAMP - RED
LED steady on: low alarm
LED flashing slow: medium alarm
LED flashing fast: high alarm
