- 86 -
Notes
Unit dimensions
Length mm 5240
(with towbar in towing position) mm 6770
Width mm 2210
Height mm 2350
Weight (ready to operate) kg TBD*
Weight (without fuel) kg TBD*
*) TBD = Data to be defined
1) At reference conditions, if applicable, and in normal shaft speed, unless otherwise stated.
2) Data Measured according to Tolerance
Free air delivery ISO 1217 ed. 3 1996 annex D ± 5% 25 l/s <FAD<250 l/s
± 4% 250 l/s <FAD
The international standard ISO 1217 corresponds to following national standards:
British BSI 1571 part 1
German DIN 1945 part 1
Swedish SS-ISO 1217
American ANSI PTC9
3) Air required for engine and compressor cooling, combustion and for compression
4) With filter change
