- 90 -
j = 50 mm²
i = 35 mm²
54 = green/yel.
1 = brown
Wire sections :
Color codes :
a = 1 mm²
ab = 0.75 mm²
aa = 0.5 mm²
aaa = 0.35mm²
b = 1.5 mm²
c = 2.5 mm²
d = 4 mm²
e = 6 mm²
f = 10 mm²
g = 16 mm²
h = 25 mm²
0 = black
2 = red
3 = orange
4 = yellow
5 = green
6 = blue
7 = purple
8 = grey
9 = white
Legend
K1
K0
K0
G3
M1
M
G1
G2
S1
24(k0) 24(f2) 24(c2) 24(f2)
3(c3)
19U(k0)19(k0)
19(f6) 19(f6)
19(b6)
04.2, 05.5, 06.1, 06.7, 06.10, 07.1, 08.1
24(a2)
04.2, 05.1, 07.1, 08.1
06.7
03.3
03.2
30
87
9822 0900 21/01
Applicable for PNS 1250 T3, Circuit diagram Engine and Controller
