Atlas Copco PNS 1250 Cud S3A/T3 APP User Manual

- 96 -
D1 Diode Q1 Circuit Breaker - ECM, 20A TT2 Temperature Sensor - Low Pressure
Element Temperature
D2 Diode Q2 Circuit Breaker - Emergency Stop, 20A
F1 Fuse - Fire Extinguisher, 10A Q3 Circuit Breaker - Main, 10A TT3 Temperature Sensor - Medium Pressure
Element Temperature
G1 Battery Q5 Circuit Breaker - Heater EU, 16A
G2 Battery Q6 Circuit Breaker - Heater USA, 16A TT4 Temperature Sensor - High Pressure
Element Temperature
G3 Alternator - Charging Q7 Circuit Breaker - Heater USA, 16A
G4 Battery Charger - EU R1 Heater - EU TT5 Temperature Sensor - Ambient
Temperature
G4 Battery Charger - USA R2 Heater - EU
H1-3 Lamp - Internal Lights R3 Heater - EU TT6 Temperature Sensor - Air Discharge
Temperature
H2-3 Lamps - Internal Lights R4 Heater - USA
H4-5 Lamp - Engine Warning R5 Heater - USA X1 Connector - Heaters EU
H6 Horn R6 Heater - USA X10 Connector - Cosmos
K0 Relay - Starter Motor R7 Resistor - 4.7 kOhm, Fire Extinguisher X11 Connector - Heater USA
K1 Relay - Auxiliary Starter R8 Resistor - 4.7 kOhm, End Detection Wire X12 Connector - Heater USA
K2 Relay - Heater EU S1 Switch - Battery X13 Connector - To Rear Wiring USA
K3 Relay - Heater USA S2 Switch - Emergency Stop X14 Connector - Terminal Block USA
K4 Relay - Solid State S3 Switch - Emergency Stop X2 Connector - Secondary Connector PC4003
LS5 Level Switch - Coolant S4 Switch - Internal Lights EU X3 Connector - Heaters EU
LT1 Level Sensor - Fuel Level S5 Switch - External Fuel Supply X4 Connector - To Rear Wiring EU
LT2 Level Sensor - Oil Level S6 Switch - Heaters EU X5 Connector - Can Engine
M1 Motor - Starter S8 Switch - Heaters USA X6 Socket - Power EU
N1 Detection Module S9 Switch - Internal Lights USA X7 Connector - Terminal Block EU
N4 Engine Control Module TS1 Temperature Switch - Heater EU X8 Socket - Power USA
PS1 Pressure Switch - Manual Actuator TS2 Temperature Switch - Heater EU X9 Socket - Power USA
PT2 Pressure Sensor - Compressor Intercooler
Pressure 2
TS3 Temperature Switch - Heater EU Y1 Solenoid - Loading Valve
TS4 Temperature Switch - Heater USA Y2 Solenoid - Oil Level Maintainer Valve
PT3 Pressure Sensor - Compressor Intercooler
Pressure 1
TS5 Temperature Switch - Heater USA Y3 Refinery Equipment - Air Shut-off Valve
TS6 Temperature Switch - Heater USA Y4 Solenoid - Blow-off Valve
PT4 Pressure Sensor - Air Discharge Pressure TT1 Temperature Sensor - Compressor Oil
Temperature
Y6 Solenoid - Automatic Actuator
PT5 Pressure Sensor - Compressor Oil Pressure Y7 Solenoid - Automatic Actuator
