ATtiny13A
Table 10-4 and Table 10-5 relate the alternate functions of Port B to the overriding signals
shown in Figure 10-5 on page 54.
Note: 1. 1 when the fuse is “0” (Programmed).
Table 10-3. Port B Pins Alternate Functions
Port Pin Alternate Function
PB5
RESET
: Reset Pin
dW: debugWIRE I/O
ADC0: ADC Input Channel 0
PCINT5:Pin Change Interrupt, Source 5
PB4
ADC2: ADC Input Channel 2
PCINT4: Pin Change Interrupt 0, Source 4
PB3
CLKI: External Clock Input
ADC3: ADC Input Channel 3
PCINT3: Pin Change Interrupt 0, Source 3
PB2
SCK: Serial Clock Input
ADC1: ADC Input Channel 1
T0: Timer/Counter0 Clock Source.
PCINT2: Pin Change Interrupt 0, Source 2
PB1
MISO: SPI Master Data Input / Slave Data Output
AIN1: Analog Comparator, Negative Input
OC0B: Timer/Counter0 Compare Match B Output
INT0: External Interrupt 0 Input
PCINT1:Pin Change Interrupt 0, Source 1
PB0
MOSI:: SPI Master Data Output / Slave Data Input
AIN0: Analog Comparator, Positive Input
OC0A: Timer/Counter0 Compare Match A output
PCINT0: Pin Change Interrupt 0, Source 0
Table 10-4. Overriding Signals for Alternate Functions in PB[5:3]
Signal PB5/RESET/ADC0/PCINT5 PB4/ADC2/PCINT4 PB3/ADC3/CLKI/PCINT3
PUOE RSTDISBL
(1)
• DWEN
(1)
00
PUOV100
DDOE RSTDISBL
(1)
• DWEN
(1)
00
DDOV debugWire Transmit 0 0
PVOE 0 0 0
PVOV 0 0 0
PTOE000
DIEOE
RSTDISBL
(1)
+ (PCINT5 •
PCIE + ADC0D)
PCINT4 • PCIE + ADC2D PCINT3 • PCIE + ADC3D
DIEOV ADC0D ADC2D ADC3D
DI PCINT5 Input PCINT4 Input PCINT3 Input
AIO RESET Input, ADC0 Input ADC2 Input ADC3 Input
