Atmel ATtiny13A User Manual

162
8126F–AVR–05/12
ATtiny13A
22. Ordering Information
Notes: 1. Code indicators:
– H or 7: NiPdAu lead finish
– U, N or F: matte tin
– R: tape & reel
2. All packages are Pb-free, halide-free and fully green and they comply with the European directive for Restriction of Hazard-
ous Substances (RoHS).
3. Topside marking for ATtiny13A:
– 1st Line: T13
– 2nd Line: Axx
– 3rd Line: xxx
4. These devices can also be supplied in wafer form. Please contact your local Atmel sales office for detailed ordering informa-
tion and minimum quantities.
5. For typical and Electrical characteristics for this device please consult Appendix A, ATtiny13A Specification at 105°C.
6. For typical and Electrical characteristics for this device please consult Appendix B, ATtiny13A Specification at 125°C.
Speed (MHz) Power Supply (V) Ordering Code
(1)
Package
(2)
Operation Range
20 1.8 - 5.5
ATtiny13A-PU
ATtiny13A-SU
ATtiny13A-SUR
ATtiny13A-SH
ATtiny13A-SHR
ATtiny13A-SSU
ATtiny13A-SSUR
ATtiny13A-SSH
ATtiny13A-SSHR
ATtiny13A-MU
ATtiny13A-MUR
ATtiny13A-MMU
(3)
ATtiny13A-MMUR
(3)
8P3
8S2
8S2
8S2
8S2
8S1
8S1
8S1
8S1
20M1
20M1
10M1
(3)
10M1
(3)
Industrial
(-40°C to +85°C)
(4)
ATtiny13A-SN
ATtiny13A-SNR
ATtiny13A-SS7
ATtiny13A-SS7R
8S2
8S2
8S1
8S1
Industrial
(-40°C to +105°C)
(5)
ATtiny13A-SF
ATtiny13A-SFR
ATtiny13A-MMF
ATtiny13A-MMFR
8S2
8S2
10M1
(3)
10M1
(3)
Industrial
(-40°C to +125°C)
(6)
Package Type
8P3 8-lead, 0.300" Wide, Plastic Dual Inline Package (PDIP)
8S2 8-lead, 0.209" Wide, Plastic Small Outline Package (EIAJ SOIC)
8S1 8-lead, 0.150" Wide, Plastic Gull-Wing Small Outline (JEDEC SOIC)
20M1
20-pad, 4 x 4 x 0.8 mm Body, Lead Pitch 0.50 mm, Micro Lead Frame Package (MLF)
10M1
10-pad, 3 x 3 x 1 mm Body, Lead Pitch 0.50 mm, Micro Lead Frame Package (MLF)
