Cross Conversion
When an AtomX SDI Expansion module or ATOMOS CONNECT is attached to your NINJA
V+, you can cross convert signals between HDMI and SDI.
This means that where HDMI sources are connected to your NINJA V+, an SDI signal can
be output from both of the BNC connectors on your AtomX SDI Expansion Module. In this
scenario, both BNC connectors on the module can be used for two simultaneous SDI out-
puts, which allows you to output the same signal to two monitors.
The SDI connector on ATOMOS CONNECT is an Input only, so HDMI signals
connected to your NINJA V+ cannot be output via SDI with an
ATOMOS CONNECT.
Where an SDI video signal is connected to your AtomX SDI Expansion module or
ATOMOS CONNECT, you can output an HDMI signal over the HDMI Out connector on your
NINJA V+.
Whilst converting the signals listed above, you can use the Output Options in the Output
menu to downscale and crop the signals. The HDR section provides options for outputting
HDR versions of the signals after cross conversion. For more information refer to the "Out-
put Menu" on page 108 section.
.
To use the cross conversion feature, firmware version 10.65 or later needs
to be installed on your NINJA V+. Once you have installed this firmware,
cross conversion will happen automatically and does not need to be
enabled.
