Mode
When connected to an SDI source, tapping on Mode will toggle between the following
modes:
l
Single Mode: For single SDI sources, where a single SDI input on either the Channel
1 or Channel 2 connector.
l
Dual Mode: Selects both SDI connectors to deliver the input signal as a dual-link
connection, where two SDI cables are connected for dual link 1.5G/3G and 6G stand-
ards.
l
Auto Select: Your NINJA V+ automatically detects the correct mode to use, based
on the signal that it is receiving.
l
Channel Source / Link Status
In Single Mode, a Channel Source indicator will appear and display the currently selected
channel. Where you have two different SDI sources connected, you can tap Channel
Source to switch between SDI connector 1 and 2. Single link SDI connections will auto-
matically be configured based on the signal input between 12G/6G/3G/HD.
In Dual mode, a Link Status Indicator will display the status of your signals. Channel 1
and/or 2 will be red when the signal is not present, whilst they will both be green when
both receiving a signal.
Compatibility Mode (SDI)
Where SDI has been selected as your input, a Compatibility Mode toggle switch will be vis-
ible under Source. This mode improves the signal locking process over SDI, when working
with specific cameras that use a slightly different version of the 12G standard. For more
information refer to atomos.com/support
