SC1000 Fiber Laser Cutting CNC System User’s Manual Version： V1.00
2017 年 3 月 27 日
Correction
parameters
Enable vertic
Don’t select
Corrected the Y axis
Corrected the X axis
AB Length(mm)
100.000
AC Length(mm)
100.000
L1 Length(mm)
100.000
L2 Length(mm)
100.000
Pitch compensate
No compensate
Only compensate
X axis 0.000 mm
Y axis 0.000 mm
Complete pitch
compensate
Go Origin
Use Z Phase Signal
Don’t select
Sample Signal Type
Origin
The user can select the limit
signal or the origin signal
Limit Switch Type
Normal Open
Fast Speed(mm/s)
50.00
Slow Speed(mm/s)
10.00
X-Axis
Go Origin Direction
Positive
Go Origin Offset(mm)
10.00
Y-Axis
Go Origin Direction
Positive
Go Origin Offset(mm)
10.00
Attention
 Motion control axis’ parameters are basic, please set up properly or it may occur error during
running.
 If Y axis is double drive, please select “Double Drive”.
 When the feedback direction of encoder is different from the real running direction, please select
“Encoder Reverse”.
 SC1000 can support two kinds of axis limited switch: NPN photoelectric switch/ mechanical switch,
user can set up as normal open/close.
