Input connectors:
CLIP
PAGING
Zone 8
Line 5 Line 4
Line 3
Line 6
Mic 1
Mic 2
-14 +9
PHANTOM
GAIN
-50 0
MTX88
AUDAC
Caution: Only use
fuses of the same type
Warning: Do not
expose this equipment
to rain or moisture
GAIN
MID
-15 +15
HIGH
-15 +15
LOW
-15 +15
MID
-15 +15
HIGH
-15 +15
LOW
-15 +15
PHANTOM
GAIN
-50 0
AC Input
100-240V 50/60Hz
Fuse: T1AL/250V
ETHERNET
RS-232
WP
GND R+ R-
GND
L+
L-
Zone 7
WP
GND R+ R-
GND
L+
L-
Zone 6
WP
GND R+ R-
GND
L+
L-
Zone 5
WP
GND R+ R-
GND
L+
L-
Zone 4
WP
GND R+ R-
GND
L+
L-
Zone 3
WP
GND R+ R-
GND
L+
L-
Zone 2
WP
GND R+ R-
GND
L+
L-
Zone 1
WP
GND R+ R-
GND
L+
L-
CLIP CLIP
CLIP
CLIP
CLIP
GND
+24 V
-14 +9
GAIN
-14 +9
GAIN
-1
4 +9
GAIN
WP
RCA / Cinch Line inputs:
UnbalancedLine-Levelinputsources(E.g.CD-Players,Tuners,MP3Players,...)
shouldbeconnectedtotheLinelevelinputsLine3toLine6.Thesearestandardline-
levelstereoinputsperformedwithRCAconnectors.Allofthemhaveagaincontrol
potentiometerwherebytheleveloftheinputsignalcanbecontrolledwithinarangeof
-14dB~+9dB.
TheclippingLEDilluminateswhenthesignalreachestheclippinglevel.
Balanced microphone inputs:
Balancedmonosources(E.g.Microphones)shouldbeconnectedtoinputsMic1andMic
2.BothchannelsareperformedwithFemaleXLRconnectorprovidedwithgaincontrol
potentiometerwherebytheleveloftheinputsignalcanbecontrolledwithinarangeof
-50dB~0dB.ThismakesitpossibletoconnectbothLinelevelinputsourcesaswellas
Microphonelevelinputsources.TheclippingLEDilluminateswhenthesignalreachesthe
clippinglevel.

Inaddition,bothchannelshaveathree-bandtonecontrolwherebyspecificfrequency
rangescanbeadjustedwithinarangeof±15dBandaphantompowerswitch,whereby
the15Voltsphantompowercanbeenabledforpoweringcondensermicrophones.
