Setting Manual IP Addresses
If you aren’t using DHCP to automatically set IP addresses, you must set them manually on the DLC and
Mac to ensure the two devices are communicating correctly.
System Preferences > Network > Ethernet Tab > Configure IPv4 Manually
Example:
Choose a unique IP address by changing ‘X’ to a
number between 1-254, the number must be dierent
on the DLC module and the computer:
192 . 168 . 100 . X
Set the Subnet Mask to:
255 . 255 . 255 . 0
We recommend leaving the Router settings blank.
On the DLC Module, press the Setup Button. The OLED displays will show the first page of the console setup. Using the
Page Keys underneath the first encoder, page to the right and ensure that Use DHCP is set to ‘NO’ in the next menu.
Setup Button
To Next Page
