page 10 – 2
D-70 / Apr 2000
TAPE REMOTE MODULE
Tape Remote Module
(TR-70; optional)
Module Overview
This optional module offers full-function control of a tape
machine with buttons marked as RTZ, FF, REW, PLAY, REC and
STOP. LED indicators in each switch function as tallyback indica-
tors and are powered by the source machine. There are no internal
connections between the tape remote panel and the console’s power
rails.
All user wiring to and from the TR-70 module takes place at two
twelve-conductor connectors mounted on the module’s rear panel.
REMOTE
PLAY
REC
STOP
REW
FF
RTZ
