AudioCodes C470HD - Rear View of the Phone

CHAPTER2 Setting up the Phone
C470HD | Users & Administrator's Manual
Rear View
Theportslocatedontherearofthephonearedescribedinthetable.
Figure 2-2: Rear View
Table 2-2: Rear View Description
# Description
1 12VDCpowerjackthatconnectstotheACpoweradapter.
2 RJ-45porttoconnecttotheEthernetLANcablefortheLANconnection(uplink-
10/100/1000Mbps).Ifyou'reusingPoweroverEthernet(PoE),powertothephone
issuppliedfromtheEthernetcable(drawspowerfromeitherasparelineorasignal
line).
3 RJ-45porttoconnectthephonetoaPC(10/100/1000Mbpsdownlink).
4 Headsetjack,i.e.,RJ-9portthatconnectstoanexternalheadset.
- 15 -
