AudioCodes Mediant 1000

Survivable Branch Appliance
AudioCodes Enhanced Media Gateway 18 Document #: LTRT-18206
2.1.1.2 Rear-Panel Description
The Mediant 1000B chassis’ front panel is displayed in the figure below and described
in Table 2-2.
Figure 2-2: Rear-Pa
nel Components
Table 2-2: Rear-Panel Component Descriptions
Item # Label Description
1
Protective earthing screw.
2
ESD Electrostatic Discharge (ESD) socket.
3
100-240V~1A Dual AC Power Supply Entries.
4
OSN3 OSN3 AMC module.
5
HDD Main Hard-disk drive (HDD) AMC module for OSN3 platform.
6
HDD Second, optional HDD for OSN3 platform.
7
- Empty AMC module slots.
