RXV81 MTR on Android Video Collaboration Bar
User's & Administrator's Manual 8 Document #: LTRT-18259
1.2 Benefits
◼ Intuitive meeting experiences with one click to join using the Microsoft Teams Rooms on
Android application.
◼ An easy-to-use mounting element and minimal cable connections enable quick and simple
deployment.
◼ Superior audio via a full-room pickup with no need for an additional external USB microphone
or speaker.
◼ Effortlessly manage meetings using the dedicated Bluetooth remote control or RX-PAD
Meeting Room Controller.
◼ Audio notifications triggered by RX-PAD are heard through the RXV81 speaker, including
Talkback accessibility, to ensure a streamlined and accessible communication experience
during meetings and collaboration sessions.
1.3 Hardware Features
◼ RXV81 can be used on an ad hoc basis as a USB A/V peripheral for any UC client
◼ Wide-angle lens with 110° field of view (FoV) covers every seat in the meeting room. D: 120º/
H: 110º/ V: 75º
◼ Adjustable camera position with ePTZ support - 5x zoom - digital 5x zoom in. Manually
vertically (up/down) adjustable ±15º.
◼ 6-element microphone array with 4.5 m pickup range for mid-size rooms and a 10W speaker
for superb sound
◼ Stylish design and finish.
◼ Built-in dual band Wi-Fi and Bluetooth.
◼ High Dynamic Range (HDR) automatically ON - Wide Dynamic Range (WDR).
1.4 Bundles
RXV81 is available in three bundles.
Table 1-1: RXV81 Bundles
1.5 Management
RXV81 bundles are managed using AudioCodes’ One Voice Operations Center (OVOC) Device
Manager or Microsoft’s Teams admin center (TAC), enabling IT admins to monitor and upgrade the
devices from anywhere. Using OVOC, IT admins can easily monitor and manage all bundled devices
from a centralized location. Management includes:
◼ Firmware management / upgrade
◼ Alarm management
◼ Upgrade the MTR APK
Admins can monitor the status of the device’s modules from the System State page as shown here.
