User's & Administrator's Manual Contents
Version 2.4 9 RXV81 MTR on Android Video Collaboration Bar
1.6 Specifications
The following table shows RXV81 specifications.
Table 1-2: Specifications
▪ Ultra HD 4k image sensor
▪ Super-wide angle horizontal field of view: 110°
▪ Lens: Fixed focus
▪ ePTZ capable, digital 5x zoom in
▪ Output resolution: 1080p
▪ Frame rate: 30 fps
▪ Manually adjustable, vertically (up/down) ±15º
▪ High Dynamic Range (HDR) automatically ON - Wide Dynamic Range
(WDR).
▪ Full duplex, noise suppression, acoustic Echo Cancellation, voice
separation
▪ 6x beamforming microphone array
▪ Voice pickup range: 4.5m (15ft)
▪ 10W speaker
▪ HDMI Output to TV
▪ Power/reset button
▪ USB 3.0 Type A (host) marked 1 to allow touch LCD or connectivity to
wireless KB via BT USB dongle
▪ Ethernet: 10/100 Mbps (RJ-45) network interface
▪ USB2.0 Type-C (device) marked 2 to connect to PC/MAC BYOD device
(peripheral mode)
▪ 3 status LEDs indicating camera on/off, mute on, call state, device
health
▪ Wi-Fi (dual band support)
▪ Bluetooth 5.0
▪ 12V/3A DC power input
▪ Remote Controller (Bluetooth managed)
▪ RX-PAD Meeting Room Controller
▪ DIMENSIONS (W X D X H) 462 x 93 x 76 mm
▪ WEIGHT 1.464 kg
▪ TCP/IP (IPv4), DHCP/ static IP; Time and date synchronization via
SNTP; VLAN support; QoS support: IEEE 802.1p/Q tagging (VLAN)
▪ Layer 3 TOS and DSCP RTCP support: (RFC 1889)
▪ IP address configuration: TCP/IP (IPv4), DHCP/static IP Time and date
synchronization: SNTP
▪ QoS support: IEEE 802.1p/Q tagging (VLAN), Layer 3 TOS and DSCP
RTCP support: (RFC 1889)
▪ Encryption: TLS (Transport Layer Security), SRTP encryption for
media, AES256
▪ Network Access Control: IEEE 802.1x
▪ Built-in certificate
▪ AudioCodes Device Manager, a plugin of AudioCodes One Voice
Operations Center (OVOC)
Microsoft Teams
Features (Android MTR)
✓ Calendar integration (with meeting preview) and one click to join
Teams meetings
✓ Meet now option
