ADVANCED MANUAL / Bit One /
52
12. DRC - DIGITAL REMOTE CONTROL
The DRC is the Bit One remote control system. It is a microprocessor digital system; it controls and monitors also the
amplifiers equipped with the ACLink bus control, if present.
When the Bit One is turned on the first time, the display will show the Firmware version installed in the DRC. The
same information will be shown on the main screen of the PC software.
When the Bit One is set up through the PC, the DRC can stay connected but its display will show the message “PC
control - DRC is disabled”. Once the set up is completed, you must use the DRC.
The DRC features are:
- Bit One turning on / off;
- Main volume control;
- Subwoofer volume control;
- Right / left balance control;
- Front / rear fader control;
- Set sources selection;
- Memory selection;
- Dynamic EQ activation (if set);
- MASTER source level control activation.
Volume control
Default function
Volume can be adjusted either by turning the
main knob or pressing button 1 and then turning
the knob. The volume range goes from -60
(min.) to 0 dB (max.).
To access to the right/left balance push button 2
and turn the knob to adjust it.
To access to the front / rear balance adjustment
press button 3 and turn the knob to adjust it.
The independent volume for the Subwoofer only
acts if a channel named Subwoofer has been
set during the set up. Press button 4 and turn
the knob for an adjustment from -12 (min) to 0 B
( from -11.5 to 0 dB at 0.5 steps).
*
These options are available only if
activated during the first set up process,
o if added afterwards during the Bit One
setup through the PC.
DRC controlled by PC
Quick pressure
release
Press for 2 seconds
PRESS
1
2
3
4
Main screen
PRESS
PRESS
PRESS
PRESS
Select
the Input.
Back to Master
PRESS
PRESS
TURN
1 2 3 4
Bit One ON
Bit One OFF
12
