ADVANCED MANUAL / Bit One /
38
This section shows all the functions of the Bit One input
sources as displayed by the software. Following please note
the description of each of the points marked with the numbers
as per the above image:
The top window shows the Bit One inputs graphically.
If you click on the input selected during the Bit One setup,
that input will become active and the Bit One will reproduce
the sound that is applied to it.
This window shows the Bit One input active source.
9.9 EXT. SOURCE EQ
Example of equalization dedicated to the PHONE input
Tab showing the typology of system previously set
with MASTER input (High/Lo-Level). It also lists the
selectable channels.
The “Select Input” section shows a list of buttons
corresponding to the inputs that have been selected
during the product setup.
If you click on the button of an input, that input will become
active and the Bit One will reproduce the sound that is
applied to that input. Also, the selected input automatically
lights up in the two Bit One images on the top. See point n. 3.
If during the setup no external sources have been selected,
they can be added or removed as follows: select the
“Config / External Source” menu
(see Fig.1), then select or
deselect the desired source.
1
2
3
4
3
2
1
5
6
4
87
Fig.2
Fig.1
8
9
