ADVANCED MANUAL / Bit One /
59
14. TECHNICAL SPECIFICATIONS
Power supply
Voltage 11 ÷ 15 VDC
Idling current 0.45 A
Switched off without DRC <0.5 mA
Switched off with DRC <1.8 mA
Remote IN voltage 7 ÷ 15 VDC (1.3 mA)
Remote OUT voltage (Bit One) 12 VDC (20 mA)
Remote OUT voltage (Bit One.1) 12 VDC (130 mA)
Signal stage
Distortion - THD @ 1 kHz, 1 VRMS Output 0.002 %
Bandwidth @ -3 dB 4.5 ÷ 21k Hz
S/N ratio @ A weighted
Digital Input 112 dB
Master Input 96.5 dB
AUX Input 100 dB
Channel Separation @ 1 kHz 77 dB
Input sensitivity (Pre In) 0.3 ÷ 5 V
Input sensitivity (Speaker In) 1.2 ÷ 20 V
Input impedance (Pre In) 20 kΩ
Input impedance (Speaker In) 5 kΩ
Max Output Level (RMS) @ 0.1% THD 4 V
Input stage
Low level (Pre) Ch1÷Ch6, AUX1 L/R, AUX2 L/R
High Level (Spk) Ch1÷Ch8, Phone IN
Digital Coaxial, Optical (S/PDIF Max 48 kHz/24 bit)
Output stage
Low level (Pre) Ch1÷Ch8
Digital ADLink (Ch1÷Ch8 S/PDIF)
Connection
From / To Personal Computer 1 x USB / B (2.0)
To Audison Electronics 2 x ACLink control bus
Crossover N. 8 (one each output channel)
Filter type Full / High Pass / Low Pass / Band Pass
Filter mode and slope Linkwitz @ 12 / 24 / 36 / 48 dB
Butterworth @ 6 / 12 / 18 / 24 / 30 / 36 / 42 / 48 dB
Crossover Frequency 70 steps @ 10 ÷ 20k Hz
Phase control 0° / 180°
Equalizer
On High Level Inputs (Speaker In) Automatic De-equalization
On AUX Inputs N.4 x Graphic: ±12 dB @ 31 Band, ISO 1/3 Oct, 20 ÷ 20k Hz
On Outputs N.8 x Graphic: ±12 dB @ 31 Band, ISO 1/3 Oct, 20 ÷ 20k Hz
Dynamic Equalization Self-adjusting System between low and high listening levels
Time Alignment
Distance 2.8 ÷ 748 cm / 1.1 ÷ 294.5 inches
Delay 0 ÷ 22 ms
Step 0.08 ms, 2.8 cm, 1.1 inch
Size
W (Width) x H (Height) x D (Depth) mm/inch 150 x 32.3 x 225 / 5.90” x 1.27” x 8.85”
Weight kg/lb 1,345 / 2.965
14
