Multi-turn actuators SA 07.1 – SA 16.1
with actuator controls AMB 01.1/AMB 02.1 Operation instructions
Other information
EC directives Electromagnetic Compatibility (EMC): (89/336/EEC)
Low Voltage Directive: (73/23/EEC)
Machinery Directive: (98/37/EC)
Reference documents Product description “Electric multi-turn actuators SA”
Dimension sheets SA
Electrical data sheets SA
Technical data sheet SA
Supply voltage Refer to name plate
Motor controls reversing
contactors:
mechanical, electrically interlocked, max. 690 V AC, max. 7.5 kW
Control voltage Standard: 230 V AC from internal power supply unit, also available for input signals
OPEN-STOP-CLOSE/ OPEN-CLOSE and for external indication lights
(P max = 2.5 W)
Option: 115 V AC from internal power supply unit
Binary inputs
(input signals)
Nominal voltage:
Standard: OPEN-STOP-CLOSE, EMERGENCY-STOP
Option: OPEN-CLOSE, EMERGENCY-STOP
Standard: 230 – 240 V AC from internal power supply unit (non potential-free)
Option: 24 V DC externally supplied (potential-free via relay)
Binary outputs Standard: End position OPEN/ end position CLOSED (non potential-free)
Option: End position OPEN / end position CLOSED (potential-free) in combination
with tandem limit switches in multi-turn actuator.
Selector switch LOCAL/ selector switch REMOTE (potential-free)
Relay outputs
(potential-free)
Version B01:
without relay board (see binary outputs)
Version B02:
Thermoswitch or overload relay tripped (NO contact)
Signal: Torque switch tripped in mid-travel (change-over contact).
Version B03:
see binary outputs
Version B04:
Thermoswitch or overload relay tripped (NO contact)
Signal: Torque switch tripped in mid-travel (change-over contact).
Local controls Standard: Selector switch LOCAL-OFF-REMOTE, lockable
Push-buttons OPEN-STOP-CLOSE
Option: Push-buttons OPEN-CLOSE, EMERGENCY-STOP
Indication lights end position OPEN, FAULT
1)
, end position CLOSED
Enclosure protection Same as actuator
Temperature range Same as actuator
Electrical connection
Standard: AUMA plug/socket connector with screw type connection
Threads for cable glands Standard: Metric thread
Options: Pg thread, NPT thread, G thread
1) Only in conjunction with version BX02 and BX04
Table 2: Technical data actuator controls AMB 01.1/AMB 02.1
