AUMA SA 07.1 Operation & Instruction Manual

4. Additional information to the wiring diagram legend
Information A: Change-over switch S9 for changing the type of seating (see subclause
19.2, page 23).
Information B: Self-retaining in local operation can be cancelled by cutting the link B3 (see
subclause 19.3, page 24).
Information C: Plug-in link for operation mode REMOTE (see subclause 19.4, page 24).
Information E: The control voltage is 115 V or 230 V AC (according to order) and must only
be switched via potential-free contacts.
End position signal: 115 V or 230 V AC, max. 2.5 W.
Information F: Instead of a link, an EMERGENCY switch with NC contact can be used.
Connections XK 49 and XK 50 carry control voltage (115 or
230 V AC) and must only be opened via the potential-free
contact.
Information G: (Versions B02 and B04 only)
Plug-in link for potential-free feedback (see subclause 19.6, page 25).
5. Transport and storage
.
Transport to place of installation in sturdy packing.
.
Do not attach ropes or hooks to the handwheel for the purpose of lifting by
hoist.
.
If multi-turn actuator is mounted on valve, attach ropes or hooks for the
purpose of lifting by hoist to valve and not to multi-turn actuator.
.
Store in well-ventilated, dry room.
.
Protect against floor dampness by storage on a shelf or on a wooden
pallet.
.
Cover to protect against dust and dirt.
.
Apply suitable corrosion protection agent to bright surfaces.
If multi-turn actuators are to be stored for a long time (more than 6 months),
the following points must be observed additionally:
.
Prior to storage: Protect bright surfaces, in particular the output drive parts
and mounting surface, with long-term corrosion protection agent.
.
Check for corrosion approximately every 6 months. If first signs of
corrosion show, apply new corrosion protection.
After mounting, connect actuator immediately to electrical system, so that
condensation is prevented by the heater.
6. Packaging Our products are protected by special packaging for the transport ex works.
The packaging consists of environmentally friendly materials which can
easily be separated and recycled.
For the disposal of the packaging material we recommend recycling and
collection centres.
We use the following packaging materials: wood, cardboard, paper and PE
foil.
7
Multi-turn actuators SA 07.1 – SA 16.1
Operation instructions with actuator controls AMB 01.1/AMB 02.1
