3. Technical data
5
Multi-turn actuators SA 07.1 – SA 16.1
Operation instructions with actuator controls AMB 01.1/AMB 02.1
Features and functions
Type of duty
1)
Standard: Short-time duty S2 - 15 min.
Option: Short-time duty S2 - 30 min.
Motors 3-ph AC asynchronous motor, type IM B9 according to IEC 34
Insulation class F, tropicalized
Motor protection Standard: Thermoswitches (NC)
Self-locking yes (for output speeds from 4 to 90 rpm)
Limit switching Counter gear mechanism for end positions CLOSED and OPEN
for 1 to 500 turns per stroke (optional for 1 to 5,000 turns per stroke)
Standard: Single switch (1 NC and 1 NO) for each end position:
Options: Tandem switch (2 NC and 2 NO) for each end position, switches galvanically isolated
Triple switch (3 NC and 3 NO) for each end position, switches galvanically isolated
Intermediate position switch (DUO limit switching)
Torque switching Adjustable torque switching for directions OPEN and CLOSE
Standard: Single switch (1 NC and 1 NO) for each direction
Options: Tandem switch (2 NC and 2 NO) for each direction, switches galvanically isolated
Position feedback signal,
analogue (options)
Potentiometer or 0/4 – 20 mA
For further details see separate data sheet
Mechanical position indicator
(option)
Continuous indication, adjustable indicator disc with symbols OPEN and CLOSED
Running indication Blinker transmitter
Heater in switch compartment Standard: self-regulating PTC heater, 5 – 20 W, internally supplied
Manual operation Manual drive for setting and emergency operation, handwheel does not rotate during
electric operation
Option: Handwheel lockable
Electrical connection to the
controls
AUMA plug/ socket connector
Terminal plan KMS TP 110/001 (basic version)
Output drive types A, B1, B2, B3, B4 according to EN ISO 5210
A, B, D, E according to DIN 3210
C according to DIN 3338
Special output drives: AF, AK, AG, IB1, IB3
Service conditions
Enclosure protection according to
EN 60 529
Standard: IP 67
Options: IP 68
For both enclosure protections (IP 67 und IP 68) the terminal compartment ist additionally
sealed against the interior - double sealed
Corrosion protection Standard: KN Suitable for installation in industrial units, in water- or power plants
with a low pollutant concentration
2)
Options: KS Suitable for installation in occasionally or permanently aggressive
atmosphere with a moderate pollutant concentration (e.g. in waste-
water treatment plants, chemical industry)
KX Suitable for installation in extremely aggressive atmosphere with
high humidity and high pollutant concentration
KX-G same as KX, however aluminium-free version (outer parts)
Finish coating Standard: two-component iron-mica combination
Standard colour Standard: silver-grey (DB 701, similar to RAL 9007)
Option: Other colours are possible on request
Ambient temperature Standard: – 25 °C to + 70 °C
Option: – 40 °C to + 70 °C
Vibration resistance
according to EN 60068-2-6
1 g, from 10 Hz to 200 Hz
Lifetime
1) Based on 20 °C ambient temperature and at an average load with running torque according to Technical data SA.
2) If occasionally or permanently exposed to aggressive substances, we recommend a higher corrosion protection KS or KX
Table 1: Technical data multi-turn actuator SA 07.1 – SA 16.1
Type Operating cycles
(OPEN-CLOSED-OPEN) with
30 turns per stroke
SA 07.1 – SA 10.1 20,000
SA 14.1 – SA 16.1 15,000
