Change seating mode:
11.
Press .
➥
Display indicates:
SEATING MODE M111
VIEW
EDIT
12.
Press .
➥
Display indicates:
ENTER PASSWORD
0 * * *
:EDIT :OK C:ESC
13. Enter password:
→
Press 4 x = 0000 (default factory password).
➥
EDIT M1110
OPEN POSITION
CLOSED POSITION
EDIT M1111
OPEN POSITION
CLOSED POSITION
Use and to select between OPEN POSITION and CLOSED POSITION.
14.
Press .
➥
Display shows the set value:
EDIT M1110
OPEN POSITION
LIMIT
↵
:EDIT C:ESC
EDIT M1111
CLOSED POSITION
LIMIT
:EDIT C:ESC
Use and to select between OPEN POSITION and CLOSED POSITION.
