Owner Installation Instructions Axess Pro Series 3000 27
Parameter Min Max Default Step Unit Menu
No.
Section
Menu 4 - Light / Lock Times
ON AFTER CYCLE LIGHT TIME
Time light remains on for after a cycle
0 255 60 1 Sec 4.1 18.1
ON BEFORE OPEN CYCLE LIGHT TIME
Minimum time light is activated for prior to opening
0 25.5 0 0.1 Sec 4.2 18.1
ON BEFORE CLOSE CYCLE LIGHT TIME
Minimum time light is activated for prior to closing
0 25.5 0 0.1 Sec 4.3 18.1
Menu 5 - Motor Settings
SINGLE
PHASE
3100
SERIES
OPEN SPEED FREQUENCY
Sets the speed of the motor
15 75 50 1 HZ 5.1 Appendix C
CLOSE SPEED FREQUENCY
Sets the speed of the motor
15 75 50 1 HZ 5.2 Appendix C
THREE
PHASE
3300
SERIES
MOTOR START TIME
sets overload ignore time from the start of the motor
0.1 2.5 1.0 0.1 Sec 5.1 Appendix C
MOTOR PAUSE TIME
Sets the time for motor to come to rest
0.1 2.0 0.3 0.1 Sec 5.2 Appendix C
Menu 6 - Operating Modes
Safety Close Mode Off On On 6.1 16.1
Safety Open Mode Off On Off 6.2 Appendix C
Safety Beam Input Response Mode Sets the S.B response mode.
Options are OPEN and CLOSE cycles stop, Close cycles stop or
Close cycle reverse
OPN & CLS stop
CLS to stop
CLS to reverse
CLS to
reverse
6.3-5 Appendix C
SB REVERSE TIME 5 FULL FULL 1 Sec 6.6 Appendix C
GPI INPUT MODE configure the GPI input. Options are OSC, PED,
SWP and DAY LIGHT SAVING
OSC,
PED, DST
OSC 6.7 Appendix C
PED INPUT = SWIPE MODE Selects PED input functions as
pedestrian access swipe input
Off On Off 6.8 Appendix C
OPN INPUT N/C OPERATION
Selects operating polarity of OPN input
Off On N/O 6.9 Appendix C
STP INPUT N/C OPERATION
Selects operating polarity of STP input
Off On N/O 6.10 Appendix C
FIRE INPUT N/C OPERATION
Selects operating polarity of FIRE input
Off On N/O 6.11 Appendix C
FIRE INPUT MODE configure the fire input. Options are OPN, CLS
and PED
OPN,
CLS, PED
OPN 6.12 Appendix C
REMOTE CODE ENABLED
Selects remote transmitter coding function
Off On On 6.13 Appendix C
ACTIVITY REPORTS Select report to be output Off 255 Off 1 6.14 Appendix C
ACTIVITY REPORT ID
Selects ID for controller, sent with activity report
0 65535 0 1 6.15 Appendix C
VACATION MODE
Selects Vacation Mode - disables remote control
Off On Off 6.16 Appendix C
PASSWORD
Selects password protection for all changes
Off On Off 6.17 Appendix C
Transmitter Grouping Off On Off 6.18 Appendix C
Parameter Min Max Default Step Unit Menu
No.
Section
Fault Auto Reset
Selects Fault Auto Reset
Off On Off 6.19 Appendix C
LED Low Power Mode
Selects saving the power by turning LEDs Off
Off On Off 6.20 Appendix C
Console OSC Buttons
Selects to lock out the console buttons
Off On On 6.21 Appendix C
AUX OUT O/P can be activated by either LIGHT DRIVE ,CLOCK/
TXER/SB, OPEN or CLOSE status
LIGHT
DRIVE
6.22 Appendix C
Menu 7 - Time Clock
SET TIME / DATE Off On Off 7.1 17.1
VIEW / EDIT PROGRAMS Off On Off 7.2 17.2
SETTINGS Off On Off 7.3 17.3
Menu 8 - Diagnostics
TEST INPUTS - Controls input display status Inactive 8.1 Appendix D
TEST TRANSMITTERS (TX’ERS) 8.2 Appendix D
DISPLAY HISTORY 8.3 Appendix D
MEMORY USAGE 8.4 Appendix D
SERVICE COUNTER 60,000 8.5 Appendix D
EVENT COUNTER 8.6 Appendix D
INSTALL DATA 8.7 Appendix D
PARAMETERS 8.8 Appendix D
VERSION INFO - Firmware 8.9 Appendix D
Menu 9 - Memory Tools
CLR CONTROL 9.1 Appendix E
CLR TRANSMITTERS (TX’ERS) 9.2 Appendix E
Menu 10 - Setup Travel
SETUP LIMITS 10.1 11.1 or 12.4
REPROFILE TRAVEL 10.2 12.5
SET PEDESTRIAN 10.3 15.1
Appendix
A - Console Menu Structure
To Next Page
