Automation Direct Stellar SR55 Series User Manual

Chapter 3: Configuration and Parameters
Page 3–5Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
Auto Setup Parameter Settings (continued from previous page)
# Application Start pedestal Stop pedestal Start time Soft stop time Trip Class Current limit level Current limit time Optimize rate Auto pedestal Auto End Start 2 Auto End Start 1 Auto End 3 Delta Operation Auto stop Soft stop smoothing spare Auto ramp Auto end stop Impact load Current limit - stopping Current limit time - stopping
– Unit % % s s – FLC s – En En En En En En En En En En En FLC s
29
Pump -
Submersible
Rotodynamic
10 10 10 60 10 3�5 25 5 1 0 0 0 1 1 1 1 0 1 0 2 25
30
Pump - Positive
displacement
Reciprocating
10 10 10 60 20 3�5 25 15 1 0 0 0 1 1 1 0 0 1 0 2 25
31
Pump - Positive
displacement
Rotary
10 10 10 60 20 3�5 25 15 1 0 0 0 1 1 1 0 0 1 0 2 25
32 Pump Jack 40 10 10 0 20 3�5 40 5 1 0 1 0 1 0 0 0 0 0 1 8 2
33 Rolling mill 40 10 10 0 20 3�5 40 5 1 0 1 0 1 0 0 0 0 0 0 8 2
34 Roots Blower 30 10 10 0 20 4�5 25 5 1 0 1 0 1 0 0 0 0 0 0 8 2
35 Saw - Band 10 10 10 0 10 3�5 25 5 1 0 1 0 1 0 0 0 0 0 0 8 2
36 Saw - Circular 40 10 10 0 20 3�5 40 5 1 0 1 0 1 0 0 0 0 0 0 8 2
37 Screen - vibrating 40 10 10 0 20 4�5 40 5 1 0 1 0 1 0 0 0 0 0 0 8 2
38
Shredder
40 10 10 0 30 3�5 60 5 1 0 1 0 1 0 0 0 0 0 0 8 2
39
Transformers,
voltage regulators
10 10 5 0 10 3�5 25 5 0 0 0 0 1 0 0 0 0 0 0 8 2
40 Tumblers 20 10 10 0 20 4 25 5 1 0 1 0 0 0 0 0 0 0 0 8 2
41 Wood chipper 40 10 10 0 30 3�5 60 5 1 0 1 0 0 0 0 0 0 0 0 8 2
