Chapter 3: Configuration and Parameters
Page 3–59Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails (ConTinued)
“log” menu of parameTers
Each SR55 is tested at the factory, and each unit may have a brief log history from this
testing.
evenT Times for sTarT CurrenT, TemperaTue, overload parameTers
The event time shows up on the “Start Current,” “temperature,” and “Overload” Logs. These
events are logged at the same time, which are reflected by the 10 “Event Time” parameters.
P16.0 – Event Time –
Last Peak Start Current / Last Temperature / Last Overload
Holding
Register Type:
Description:
Read Only
Displays the event time.
Range: Modbus Decimal Value: Default:
hh:mm:ss Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
GMT
Modbus Address: Modbus Format:
38464 ( 9640 hex ) 6 Bytes
Touchscreen Menu Path:
Home → Log → Start Current / Temperature / Overload →
Last Peak Start Current / Last Temperature / Last Overload
P16.1 – Event Time –
Last Peak Start Current / Last Temperature / Last Overload -1
Holding
Register Type:
Description:
Read Only
Displays the event time -1.
Range: Modbus Decimal Value: Default:
hh:mm:ss Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
GMT
Modbus Address: Modbus Format:
38467 ( 9643 hex ) 6 Bytes
Touchscreen Menu Path:
Home → Log → Start Current / Temperature / Overload →
Last Peak Start Current / Last Temperature / Last Overload -1
P16.2 – Event Time –
Last Peak Start Current / Last Temperature / Last Overload -2
Holding
Register Type:
Description:
Read Only
Displays the event time -2.
Range: Modbus Decimal Value: Default:
hh:mm:ss Time (ms) since midnight
(bytes5,4,3,2) and Days since
01/01/1984 (bytes1,0)
GMT
Modbus Address: Modbus Format:
38470 ( 9646 hex ) 6 Bytes
Touchscreen Menu Path:
Home → Log → Start Current / Temperature / Overload →
Last Peak Start Current / Last Temperature / Last Overload -2
