Chapter 3: Configuration and Parameters
Page 3–7Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
summary of parameTers for individual parameTer seTup
(grouped by TouChsCreen navigaTion)
parameTers from “advanCed” menu CaTegory – summary
Summary – Parameters for Touchscreen Setup – “Advanced” Category
Category – Advanced
Group Parameter Units Range
Read /
Write
Modbus
Default
Setting
User
Setting
Address Hex
P1�0 – Save Parameters toggle NO / YES R/W 62144 F2C0 NO
(P2)
Automatic
Settings
[detailed info
starts page
3–22]
P2�0 – Automatic Pedestal toggle OFF / ON R/W 19840 4D80 OFF
P2�1 – Automatic Ramp toggle OFF / ON R/W 20352 4F80 OFF
P2�2 –
Automatic End Start (1)
toggle OFF / ON R/W 19968 4E00 OFF
P2�3 – Automatic Stop toggle OFF / ON R/W 20160 4EC0 OFF
P2�4 –
Automatic Stop Profile
% 0 to 100 R/W 20608 5080 50
P2�5 – Automatic End Stop toggle OFF / ON R/W 20416 4FC0 OFF
P2�6 –
Automatic Impact Load
toggle OFF / ON R/W 20480 5000 OFF
P2�7 – Auto Smooth Stop toggle OFF / ON R/W 20224 4F00 OFF
P2�8 –
Auto Smoothing Level
% 10 to 100 R/W 20672 50C0 50
P2�9 –
Automatic End Start (2)
toggle OFF / ON R/W 19904 4DC0 OFF
P2�10 –
Automatic End Start (3)
toggle OFF / ON R/W 20032 4E40 OFF
P2�11 – Rate End Start (3) % 0 to 100 R/W 768 0300 50
(P3)
Start
Settings
[detailed info
starts page
3–25]
P3�0 – Start Time s 1 to 300 R/W 7104 1BC0 10
P3�1 – Start Pedestal % 10 to 100 R/W 704 02C0 20
P3.2 – Start Current Limit →
Start Current Limit Trip
toggle OFF / ON R/W 53790 D21E ON
P3.3 – Start Current Limit →
Start Current Limit Level
A
100% mtr FLA to
450% SR55 rated A
R/W 26880 6900
350%
mtr
FLA
P3.4 – Start Current Limit →
Start Current Limit Time
s 1 to 300 R/W 26944 6940 30
P3�5 –
Kick Start → Kick Start
toggle OFF / ON R/W 320 0140 OFF
P3�6 –
Kick Start → Kick Start Time
ms 10 to 2,000 R/W 7040 1B80 100
P3.7 – Kick Start →
Kick Start Pedestal
% 30 to 80 R/W 640 0280 75
P3�8 – Contactor Delay ms 20 to 800 R/W 8320 2080 160
(P4)
Stop Settings
[detailed info
starts page
3–28]
P4�0 – Stop Time s 0 to 300 R/W 7296 1C80 0
P4�1 – Stop Pedestal % 10 to 40 R/W 896 0380 10
P4.2 – Stop Current Limit →
Stop Current Limit Trip
toggle OFF / ON R/W 53791 D21F OFF
P4.3 – Stop Current Limit →
Stop Current Limit Level
A
100% mtr FLA to
450% SR55 rated A
R/W 28800 7080
350%
mtr
FLA
P4.4 – Stop Current Limit →
Stop Current Limit Time
s 1 to 300 R/W 28864 70C0 10
