Chapter 3: Configuration and Parameters
Page 3–21Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails – “auTo seTup” menu of parameTers (ConTinued)
P7.0 – Control Method Holding Register Type:
Description: Read/Write
• Local Touch Screen : Control using the buttons on the keypad.
• User Programmable : Control using the terminals, function defined in “I/O” menu.
• Two Wire Control : Control using terminals; functions fixed as shown on screen.
D1-1I = High: Reset & Start / Low: Stop
• Three Wire Control : Control using terminals; functions fixed as shown on screen.
D1-1I = High Start
D1-2I = Low Stop
D2-1I = High Reset
• Modbus Network : Control via remote Modbus network or remote touchscreen.
Range: Modbus Decimal Value: Default (decimal):
• Local Touch Screen
• User Programmable
• Two Wire Control
• Three Wire Control
• Modbus Network
• 0
• 1
• 2
• 3
• 4
• Local (0)
Modbus Address: Modbus Format:
59392 ( E800 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Auto Setup → Control Method
(also Home → Advanced → Control Method) (also Home → I/O → Digital Inputs → Control Method)
P10.0 – Digital Input Voltage Hold. Reg. Type:
Description: Read/Write
The digital inputs D1-1I, D1-2I, D2-1I are designed to work with a range of control supplies.
• It is important to ensure the “Digital Input Voltage” corresponds to the voltage applied to the
input. Failure to do so may result in damage.
Range: Modbus Decimal Value: Default (decimal):
• 230VAC : ‘Active high level’ Input voltage must be in
the range 195.5V–253V.
• 110VAC : ‘Active high level’ Input voltage must be in
the range 93.5V–121V.
• 24VDC : ‘Active high level’ input voltage must be in the
range 20.4V–26.4V.
• 0
• 1
• 2
• 230VAC (0)
Modbus Address: Modbus Format:
10880 ( 2A80 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Auto Setup → Digital Input Voltage
(also Home → I/O → Digital Inputs → Digital Input Voltage)
