Automation Direct Stellar SR55 Series User Manual

Chapter 3: Configuration and Parameters
Page 3–53Stellar
®
SR55 Series Soft Starter User Manual – 1st Ed, Rev F – 09/18/2019
parameTer deTails (ConTinued)
“moniTor” menu of parameTers
P15.0 – Line Frequency Type:
Description: Read Only
The frequency of the 3-phase supply.
Range: Modbus Decimal Value: Default:
45Hz – 65Hz linear scale (1 = 0.001 Hz)
Freq(Hz) = (Value / 1000)
n/a
Modbus Address: Modbus Format:
32000 ( 7D00 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Monitor → Line Frequency
P15.1 – Phase Rotation Hold. Reg. Type:
Description: Read Only
Indicates the phase sequence of the incoming supply.
Range: Modbus Decimal Value: Default (decimal):
• RYB = L1, L2, L3
• RBY = L1, L3, L2
• 0
• 1
• L1-L2-L3 (0)
Modbus Address: Modbus Format:
32064 ( 7D40 hex ) 16-bit unsigned
Touchscreen Menu Path:
Home → Monitor → Phase Rotation
P15.2 – I1 Type:
Description: Read Only
The RMS current on phase L1.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
33536/33537 ( 8300/8301 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Monitor → I1
P15.3 – I2 Type:
Description: Read Only
The RMS current on phase L2.
Range: Modbus Decimal Value: Default:
0A – 10,000A linear scale (1 = 1mA)
Current (A) = (Value / 1000)
0A
Modbus Address: Modbus Format:
33538/33539 ( 8302/8303 hex ) 32-bit unsigned
Touchscreen Menu Path:
Home → Monitor → I2
